Non Tipping Trailer

Agroking Trailers are used for the transportation of agriculture produces, farming remainders, residues or weeds from one place to another. Heavy Duty Structure using finest quality of raw material and Robust Design, results in Low Maintenance Cost and Long Life. Good Quality Paint is used that s

Product Benefits

Non Tipping Trailer

Heavy Duty Structure using finest quality of raw material and Robust Design, results in Low Maintenance Cost and Long Life. Good Quality Paint is used that saves the product from corrosion and thus enhance the life.

Specifications

MODEL	TRB 3	TRB 5	TRB 9
OUTER DIMENSION (LXWXH IN FEET)	8 X 6 X 2	10 X 6 X 1.75	12 X 6 X 2.00
MAIN CHASSIS HEAVY CHANNEL	125 X 65 MM	150 X 75 MM	200 X 75 MM
SECOND CHASSIS CHANNEL	100 X 50 MM			125 X 65 MM
SUPPORT CHANNEL	75 X 40 MM
FLOOR PLATFORM THICKNESS	4 MM	4 MM	4 MM
SIDE WALLS THICKNESS	3 MM	3 MM	3 MM
FRONT SIDE	FIXED BY BOLT AND NUTS AND REMOVABLE
LEFT, RIGHT AND REAR SIDE	ALL SIDES ARE DROP DOWN AND REMOVABLE
WHEEL RIM	HEAVY DUTY
TYRES	12.5 / 80-15.3		400 / 60-15.5
PAINTING	PU PAINT
AXLE	75 MM SQUARE		90 MM SQUARE
AXLE BEARING	32214 INNER & 32211 OUTERS			32217 INNER & 32211 OUTERS
HUB	SGI CASTING CNC MACHINED
WEIGHT IN KG (APPROX.)	1030	1145	1525
OPTIONAL	BREAK DRUM & LEAF SPRING
