Tipping Trailer Single Tyre Heavy Duty

Heavy Duty Structure using finest quality of raw material and Robust Design, results in Low Maintenance Cost and Long Life. Good Quality Paint is used that saves the product from corrosion and thus enhance the life.

Product Benefits

Landforce Trailers are used for the transportation of agriculture produces, farming remainders, residues or weeds from one place to another.

Features

Parking Stand

The parking jack must always be used when carrying out maintenance and service.

Hydraulic Cylinder

A hydraulic cylinder is a mechanical actuator that is used to give a unidirectional force through a unidirectional stroke

Hitch

Suitable for all type tractors.

Frame

Heavy Duty Frame

Specifications

MODEL	TRA 3	TRA 5	TRA 9
OUTER DIMENSION (LXWXH IN FEET)	8 x 6 x 2	10 x 6 x 1.75	12 x 6 x 2.00
MAIN CHASSIS HEAVY CHANNEL	125 x 65 MM	150 x 75 MM	200 x 75 MM
SECOND CHASSIS CHANNEL	100 x 50 MM		125 X 65 MM
SUPPORT CHANNEL	75 x 40 MM
FLOOR PLATFORM THICKNESS	4 MM	4 MM	4 MM
SIDE WALLS THICKNESS	3 MM	3 MM	3 MM
FRONT SIDE	FIXED BY BOLT AND NUTS AND REMOVABLE
LEFT, RIGHT AND REAR SIDE	ALL SIDES ARE DROP DOWN AND REMOVABLE
WHEEL RIM	HEAVY DUTY
TYRES	12.5 / 80-15.3		400 / 60-15.5
PAINTING	PU PAINT
HYDRAULIC JACK	10 TONS CAPACITY HEAVY DUTY DOUBLE STAGE TIPPING RAM 15 TONS CAPACITY HEAVY DUTY DOUBLE STAGE TIPPING RAM
AXLE	75 MM SQUARE		90 MM SQUARE
AXLE BEARING	32214 INNER & 32211 OUTER		32217 INNER & 32211 OUTER
HUB	SGI CASTING CNC MACHINED
WEIGHT IN KG (APPROX.)	1060	1175	1553
OPTIONAL	BREAK DRUM & LEAF SPRING
